MHY 15-inch fanless industrial touch panel PC with true-flat capacitive bezel

Industrial Panel PC · Fanless · IP65

Fanless Industrial Panel PC

A rugged embedded touch computer for HMI, machine control and 24/7 self-service environments. The true-flat IP65 front wipes down in dusty or wash-down areas, the sealed fanless chassis eliminates air-filter maintenance, and Windows, Android, Linux or Ubuntu lets you run the software you already certify.

✓ 10.1″–21.5″ true-flat PCAP touch, 4:3 and widescreen
✓ IP65 front bezel; fanless sealed chassis for 24/7 duty
✓ Wide-temperature -20–60 °C option for harsh sites
✓ Windows 10/11 IoT, Android, Linux, Ubuntu
✓ Panel/VESA mount; rich industrial I/O; OEM BIOS and bezel

Request a Quote Get the Datasheet

Series MHY-IPC · samples available · bulk lead time 12–20 days

Highlights

Engineered for the Plant Floor, Not the Office

🌬️

Truly Fanless Thermal Design

A finned aluminum chassis conducts CPU heat out without a fan, removing the number-one failure point in dusty environments — no air filters, no fan noise, no intake of contaminants.

💧

IP65 True-Flat Front

The edge-to-edge toughened-glass front resists water spray and dust and wipes clean quickly, making it suitable for food, pharmaceutical and outdoor-cabinet installations.

🧤

Glove & Wet-Hand Touch

Projected-capacitive touch is standard with thick-glove tuning available; a resistive option supports heavy gloves and stylus workflows where required.

🔌

Industrial I/O & Long Lifecycle

Multiple serial, USB, isolated GPIO, dual LAN and optional CAN/PoE, with controlled BOM and BIOS settings so OEM integrators avoid unexpected hardware changes.

Specifications

Technical Specifications

Representative configuration of the MHY-IPC series; sizes, CPUs and options are mixed to match each project.

Display Sizes	10.1, 12.1, 15, 15.6, 17, 19 and 21.5 inch; 4:3 and 16:9, 1024×768 to 1920×1080
Touch	Projected capacitive (PCAP) multi-touch; EETI/ILITEK controller; 5-wire resistive option
Front Panel	True-flat toughened glass, IP65 against water/dust from the front; slim aluminum bezel
Processor / OS	Intel Celeron/Core (Windows 10/11 IoT, Linux, Ubuntu) or Rockchip ARM (Android); custom OS image
Memory / Storage	4–32 GB RAM; 32 GB eMMC to 512 GB SSD; mSATA/M.2; optional second storage
Cooling	Fanless finned aluminum chassis; passive conduction, no moving parts
Operating Temperature	Standard 0–50 °C; wide-temperature SKU -20–60 °C; 10–90% RH non-condensing
Interfaces	RS-232/485 ×2–6, USB ×4–8, dual Gigabit LAN, HDMI, audio, isolated GPIO; CAN, PoE, 4G/5G and Wi-Fi options
Mounting	Flush panel mount with mounting clips, VESA 75/100 arm, desktop stand and DIN-rail accessories
Power	Wide-voltage DC 9–36 V terminal input; lockable connector; optional external adapter
Reliability	Designed for 24/7 operation; vibration and thermal-cycle tested on the production line
Certification	CE, FCC, RoHS compliant; ISO 9001 certified factory
Warranty	1 year standard, extendable to 3 years; lifetime technical support
MOQ & Lead Time	Sample MOQ 1 unit (3–7 days); bulk 12–20 days; OEM BIOS, bezel and silk-screen from agreed MOQ

Applications

Where the Panel PC Runs 24/7

🏭

Factory HMI & MES

Machine control, SCADA and production-line MES terminals in dusty or wash-down environments.

📦

Warehouse & Logistics

Forklift-mounted, packing-station and dock-door terminals with glove touch and wide-voltage DC.

🤖

Automation & Robotics

Control panels for automation cells, vision stations and robotic workcells needing serial/CAN I/O.

🚉

Transport & Outdoor Cabinets

Station, tolling and equipment-cabinet screens using the wide-temperature and IP65 configuration.

🥤

Food & Beverage

Hygienic wipe-down HMI on filling and packaging lines requiring a true-flat sealed front.

🏥

Clean & Medical Environments

Easy-to-disinfect touch terminals for cleanrooms, laboratories and hospital logistics points.

Pairs Well With

Self-service

Self-Service Kiosks

Complete enclosures when you need a finished, tested terminal rather than components.

View range →

Industrial panel PC connected as the host in a verification cabinet

Identity

ID & Passport Readers

Pair rugged host compute with MRZ/RFID document capture for e-gate projects.

View range →

19-inch Android industrial all-in-one touch panel from the same hardware family

Counter

Dual-Screen POS Terminal

Front-of-house touch hardware for staffed retail and hospitality counters.

View product →

FAQ

Industrial Panel PC FAQ

What does the IP65 rating actually cover?

The IP65 rating applies to the front panel: it is dust-tight and protected against low-pressure water jets from the front, suitable for splash and wash-down cleaning of the screen face. The rear enclosure and connectors are not IP65 and should be installed inside a protected cabinet; fully enclosed IP-rated cabinets can be supplied as an OEM project.

Can operators use it with gloves or wet hands?

Yes. The projected-capacitive controller can be tuned for thin/medium gloves and moisture; for heavy industrial gloves or stylus-only workflows MHY offers a 5-wire resistive touch version on the same chassis.

Can we lock the BOM and BIOS for a multi-year machine program?

Yes. For OEM machine builders MHY controls BOM changes, provides fixed BIOS settings (auto-power-on, wake-on-LAN, watchdog) and notifies customers before approved component substitutions, which keeps your certification and software images stable over the product lifecycle.

Which OS should we specify?

Use Windows 10/11 IoT when your SCADA/HMI software is Windows-based, Android for lightweight interactive apps and lowest cost, and Linux/Ubuntu for custom or containerized workloads. MHY ships pre-imaged, tested units with your image to remove on-site setup.

Configure Your Industrial Panel PC

Send your screen size, I/O, temperature and OS requirements — get a factory quote within 24 hours.

Request a Quote
